Product Description
Qhov noCeramics Integrated Laser Processing tshuabcombines precision txiav, micro- qhov ua, thiab precision scribing rau hauv ib qho system. Nws tau txais kev paub tab thiab ruaj khov fiber ntau nanosecond laser thev naus laus zis los muab ib qho - nres, siab - ua haujlwm tau zoo, thiab tus nqi- ua haujlwm zoo rau ntau yam ntaub ntawv ceramic xws li alumina (Al₂O₃), aluminium nitride (ALN), zirconium oxide (ZrO₂), thiab silicon carbide N(Silicon). Nws yog tshwj xeeb tshaj yog haum rau R & D thiab ntau lawm xav tau kev pab ntawm ntau yam, me me batch, thiab siab precision.
Taw qhia ntawm cov khoom sivt
Peb cov khoom siv sib xyaw ua ke ntawm cov khoom siv sib nqus sib nqus ncua kev sib nqus linear motors, 0.1μm siab -cov nplaig grating, thiab tag nrho - kaw- lub voj tsheb npav CNC, xa cov lus teb siab, precision, thiab kev saib xyuas qis. Nruab nrog CCD qhov muag pom qhov system, nws txhawb kev txiav thiab kos npe ntawm metallized ceramics thiab nti substrates. Featuring lub marble precision platform thiab XY cais kaw qauv, nws muaj zoo heev rigidity, poob siab kuj, thiab siab - ceev stability.
Vim li cas thiaj xaiv Integrated tshuab?
CovCeramics Integrated Laser Processing tshuabsawv cev rau qib siab tshaj plaws ntawm kev sib koom ua ke thiab hloov tau yooj yim hauv thaj chaw ntawm laser precision machining. Lawv tuaj yeem ua tiav ntau cov kauj ruam ua haujlwm nrog ib lub tshuab thiab ib qho chaw (lossis los ntawm kev txav ntawm lub platform precision), txhim kho kev ua tau zoo, precision, thiab tawm los.
Technical data
|
Yam khoom |
Parameter |
|
Laser wavelength |
1060-1080nm |
|
Laser tso zis zog |
150W (yeem) |
|
Max.txiav ntau yam |
300 * 300 hli |
|
Txiav thickness |
0.2-2mm (nyob ntawm cov khoom siv) |
|
Precision ntawm rov ua qhov chaw ntawm X / Y axis |
±3μm |
|
Kev ceev ceev |
0-2500mm / min |
|
Qhov siab tshaj plaws acceleration |
1.0G |
|
Qhov kev ncua deb tshaj plaws |
60m / min |
|
Worktable precision |
Tsawg dua los yog sib npaug li 0.015mm |
|
Hom kis tau tus mob |
linear motor +0.1μm grating kav |
|
Tag nrho lub tshuab fais fab (tsis muaj kiv cua) |
Tsawg dua lossis sib npaug li 6KW |
|
Tag nrho qhov hnyav ntawm tag nrho lub tshuab |
Txog 1700KG |
|
Sab nraud qhov ntev (ntev * dav * qhov siab) |
1400 * 1500 * 1800mm (Rau siv) |
Daim Ntawv Thov Tshwj Xeeb Scenarios
1. Siab -Kev Ua Haujlwm Ceramic Mechanical Seal Rings
Scribing/Cutting: Txiav cov txheej txheem txheej txheej thiab sab hauv bore contour ntawm lub nplhaib foob.
Drilling: Machining mounting qhov, caij nplooj ntoos hlav qhov, pin qhov, thiab lwm yam.
Scribing/Grinding: Machining hydrodynamic grooves (kauv zawj, T-grooves) ntawm lub ntsej muag kawg sealing. Cov micron - qhov tob tob yog qhov tseem ceeb rau kev pib lub twj tso kua mis - nres sealing thiab kev pabcuam lub neej.
2. Ntau-Channel Ceramic Nozzles/Valve Cores
Txiav: Shaping complex sab nrauv contours.
Scribing: Imprinting mus tas li cim (tus qauv naj npawb, batch tooj) sab hauv lossis sab nraud.
Scribing/Cutting: Initial or partial cutting along the script line (scribing).
Drilling: Machining los ntawm qhov los yog qhov muag tsis pom qhov chaw nyob rau hauv ib qho chaw tshwj xeeb rau kev sib txuas ntsug tom ntej, qhov cua, lossis mounting.
Fine Cutting: Faib ib qho monolithic substrate rau hauv ib qho khoom siv.
Txiav: Machining sab nraud contour ntawm lub tsev.
Drilling: Machining cheeb tsam hlau sib txuas thiab npog phaj soldering cheeb tsam.
Scribing / Engraving: Machining cov kauj ruam thiab grooves hauv kab noj hniav, los yog kos rau sab nraud.
Txiav: Txiav qhov pib contour ntawm cov ntaub ntawv saib los ntawm cov phaj ceramic.
Drilling: Precisely machining lub crown qhov, microphone qhov, barometer qhov, thiab pluaj txuas qhov, thiab lwm yam.
Fine Scribing / Engraving: Engraving hniav textures thiab teev nyob rau sab ntawm lub watch case, los yog machining nplua kua nplaum overflow grooves rau kev tshuaj ntsuam / rov qab cover bonding.
Txheej txheem thov:
Txiav: Machining irregular contours.
Drilling: Machining ntau qhov ntawm qhov sib txawv thiab cov duab rau mounting koob yees duab, flash, logos, thiab lwm yam.
Scribing/Micro-engraving: Engraving zoo heev concentric vajvoog textures los yog halo textures ntawm lub koob yees duab bezel; machining kav hlau txais xov cais thaj chaw los yog txhawb nqa cov kab nrib pleb ntawm sab hauv ntawm lub nraub qaum.
Scribing: Scribing me me roj raws ntawm cov electrolyte los yog electrode los xij kom ua tau raws li cov roj thiab huab cua.
Drilling: Machining interconnect qhov (vias) thiab manifolds (gas collection chambers).
Txiav: Txiav cov nplooj ntawv ceramic loj rau hauv qhov xav tau square lossis puag ncig ib leeg.
Scribing/Micro-txiav: Machining kev nyab xeeb nyem valve qauv los yog tso cov cim ntawm cov npoo los yog cov chaw tshwj xeeb ntawm lub tshuab cais.
Drilling: Machining micropore arrays rau hauv zos tswj ionic conductivity (rau txiav- daim ntawv thov ntug).
Txiav: Txiav lub separator mus rau qhov kawg dav.
